The NSK W3227FA-2-C5T25 is a high-precision ball screw with a finished shaft end, featuring a flanged single nut, and belongs to the FA type for industrial automation equipment.
The W3227FA-2-C5T25 ball screw has standard machined ends for easy installation and is suitable for automation equipment and precision linear drive systems requiring high speed response and smooth operation.
The main features of the W3227FA-2-C5T25 ground ball screw are as follows:
High positioning accuracy: Accuracy class up to C5, precision ground for smooth operation.
Zero axial backlash: Achieved through preload with axial backlash <0.005 mm, providing good rigidity and suitable for bidirectional precision positioning.
Compact structure: Flange-type single nut design saves installation space.
Wide applicability: Designed specifically for industrial automation equipment (FA series), commonly found in CNC machine tools, industrial robots, automotive equipment, and precision manufacturing lines.
The NSK W3227FA-2-C5T25 ball screw is commonly used in:
CNC machine tools: feed axes of CNC machining centers, lathes, and milling machines.
Automated production lines: robotic arms and material handling robots.
Precision measuring instruments: coordinate measuring machines, etc.
Item |
Specification |
Model No. |
W3227FA-2-C5T25 |
Series |
Shaft End Finished Product |
Type |
FA |
Screw Shaft Diameter [mm] |
32 |
Lead [mm] |
25 |
Accuracy Grade |
C5 |
Ball Diameter [mm] |
4.762 |
Valid Number of Laps |
2.5×1 |
Gap Symbol |
T |
Circulation Method |
Pipe Circulation |
Nut Length [mm] |
117 |
Maximum travel [mm] |
2646 |
Screw Length (Lt) [mm] |
2780 |
Screw Length (La) [mm] |
2819 |
Screw Length (L) [mm] |
2976 |
Weight [kg] |
19.1 |
Rated Dynamic Load [N] |
20400 |
Rated Static Load [N] |
42200 |
Maximum Speed [Fixed-Free] (min-1) |
570 |
Drive Side Support Unit |
WBK25-01W(Square) WBK25-11(Round) |
Reverse Drive Side |
WBK25S-01W(Square) |
