The NSK W2521FA-2-C5T20 shaft-end finished ball screw is a FA-type ball screw with a 25mm shaft diameter, 20mm lead, and C5 precision. It features single-nut preload, axial clearance ≤0.005mm, high rigidity, and strong load-bearing capacity, making it suitable for medium-to-high load automated equipment such as CNC machine tools and robots.
Features of C5 Precision Ball Screw W2521FA-2-C5T20:
Low Noise: Utilizes advanced circulation system and sealing technology for low operating noise.
High Speed Performance: Maximum speed up to 5000 min⁻¹, suitable for high-speed applications.
Zero Backlash Preload: Preload design with axial backlash <0.005mm, improving positioning accuracy and rigidity.
Precision Grade C5: High lead accuracy, suitable for applications requiring precise position control.
The NSK W2521FA-2-C5T20 ball screw is commonly used in:
CNC machine tools: feed axes of CNC machining centers, lathes, and milling machines.
Automated production lines: robotic arms and material handling robots.
Precision measuring instruments: coordinate measuring machines, etc.
Item |
Specification |
Model No. |
W2521FA-2-C5T20 |
Series |
Shaft End Finished Product |
Type |
FA |
Screw Shaft Diameter [mm] |
25 |
Lead [mm] |
20 |
Accuracy Grade |
C5 |
Ball Diameter [mm] |
4.762 |
Valid Number of Laps |
2.5×1 |
Gap Symbol |
T |
Circulation Method |
Pipe Circulation |
Nut Length [mm] |
96 |
Maximum travel [mm] |
2040 |
Screw Length (Lt) [mm] |
2150 |
Screw Length (La) [mm] |
2180 |
Screw Length (L) [mm] |
2313 |
Weight [kg] |
9.1 |
Rated Dynamic Load [N] |
18600 |
Rated Static Load [N] |
32600 |
Maximum Speed [Fixed-Free] (min-1) |
720 |
Drive Side Support Unit |
WBK20-01A(Square) WBK20-11(Round) |
Reverse Drive Side |
WBK20S-01(Square) |
