W2507FA-3P-C5Z25 Ball Screw NSK FA Type 25mm Large Ball Screw

The NSK W2507FA-3P-C5Z25 ball screw has a shaft diameter of 25 mm, a lead of 25 mm, C5 precision, and interference preload (zero backlash). The W2507FA-3P-C5Z25 preloaded ball screw has a thread length of approximately 700 mm, making it suitable for high-speed feeding and rapid positioning. It features a compact structure and smooth operation.

Features of the NSK FA type finished ball screw W2507FA-3P-C5Z25:

Low Noise: Utilizes advanced circulation system and sealing technology for low operating noise.
High Speed ​​Performance: Maximum speed up to 5000 min⁻¹, suitable for high-speed applications.
Zero Backlash Preload: Preload design with zero axial backlash, improving positioning accuracy and rigidity.
Precision Grade C5: High lead accuracy, suitable for applications requiring precise position control.

Application Industries of NSK FA type finished ball screws:
CNC Machine Tools: Machining centers, lathes, milling machines, etc.
Automation Equipment: Industrial robots, automated assembly lines, precision positioning platforms
Semiconductor Equipment: Wafer handling, testing equipment
Medical Equipment: Precision medical instruments, diagnostic equipment
Precision Measuring Instruments: Coordinate measuring machines, image measuring instruments
