W2503SA-2P-C5Z5 SA type precision shaft end finished ball screw

The NSK W2503SA-2P-C5Z5 is an SA-type precision finished ball screw, specifically designed for machine tools. It features zero backlash and high precision, allowing direct installation of bearings, couplings, and locknuts, significantly simplifying the assembly process.

Key Features of the W2503SA-2P-C5Z5 Finished Ball Screw Shaft End:

Fully Machined Shaft End: Bearing mounting positions, threads, relief grooves, keyways, etc., are all precision machined.

Ready to Use: Bearings, couplings, and locknuts can be directly installed without additional machining.

High Precision Guarantee: Strict control of shaft end coaxiality and runout ensures transmission accuracy.

Pipe Circulation: Balls circulate through a guide tube, resulting in smooth operation and low noise.

Common Applications of W2503SA-2P-C5Z5 Precision Ball Screws

CNC Machine Tools
Industrial Robots
Precision Conveying Machinery
Electronic Manufacturing Equipment
