W2004SA-2P-C5Z5 SA Type Small Lead Ball Screw NSK 20mm Diameter Ball Screw

The NSK W2004SA-2P-C5Z5 is a tubular circulating ball screw with a diameter of 20 mm, a lead of 5 mm, and a total length of approximately 600 mm. It features a right-hand thread design, C5 precision grade, and high precision, low backlash, and high-efficiency transmission characteristics.

Core Features and Advantages of the W2004SA-2P-C5Z5 Ball Screw:

Ready to Use: The SA type shaft end is precision-machined, requiring no secondary processing by the user. It can be directly matched with NSK WBK/WBN series support units, significantly shortening the assembly cycle and reducing installation costs.

Zero Backlash High Precision: The single-nut interference preload design completely eliminates axial backlash. C5 precision grade ensures extremely low positioning error, suitable for precision positioning scenarios requiring frequent forward and reverse rotation.

Compact Structure: The single-nut design saves more installation space than double-nut designs, making it suitable for miniaturized equipment. Meanwhile, the P preload provides sufficient rigidity to meet general load requirements.

In-stock: As standard NSK inventory, it boasts short delivery cycles, enabling rapid response to equipment manufacturing and maintenance needs.

Common Applications of W2004SA-2P-C5Z5 Precision Ball Screws:

CNC Machine Tools, Industrial Robots, Precision Conveying Machinery, Electronic Manufacturing Equipment
