NSK W2005FA-5PGX-C5Z40 Ball Screw 40mm Ultra-high Lead Ball Screw

The NSK W2005FA-5PGX-C5Z40 is a high-lead ball screw from the FA series, with a nominal diameter of 20 mm, a lead of 40 mm (high lead specification), and a precision class of C5. This model employs an end-cap type ball recirculation structure, ensuring smooth circulation and low noise, making it suitable for high-speed reciprocating motion applications.

The W2005FA-5PGX-C5Z40 ball screw features standard-machined ends for easy installation, making it suitable for automated equipment and precision linear transmission systems requiring high speed response and smooth operation.

Features of W2005FA-5PGX-C5Z40 Shaft-End Ball Screw:

Extra-large lead 40mm: Achieves high-speed linear motion with a shaft diameter of 20mm.

End cap circulation structure: Optimized for large lead, excellent high-speed performance.

C5 Precision Grade: High positioning accuracy, suitable for industrial precision positioning needs.

Preload structure: 0mm axial clearance, excellent rigidity and positioning stability.

Typical Applications of W2005FA-5PGX-C5Z40 Large Lead Ball Screw:

Industrial Automation

CNC Equipment

Electronic Manufacturing Equipment

Packaging/Printing Machinery

Logistics and Conveying Equipment

Electric Cylinders/Actuators
