NSK W2002FA-2-C5T10 Precision Ground Ball Screw FA Type Ball Screw

The W2002FA-2-C5T10 is an NSK FA type pre-finished ball screw, meaning that both ends of the screw shaft have been precision-machined to NSK standard support units at the factory and can be directly installed and used. The NSK ball screw W2002FA-2-C5T10 has a shaft diameter of 20 mm, a lead of 10 mm, an accuracy class of C5, and uses a tubular circulation structure, suitable for positioning and reciprocating motions in general automated equipment.

The NSK A-series pre-machined FA 20×10 ball screws feature the following characteristics:

shaft end finished : The mounting section and threads are pre-machined at the factory, allowing for direct assembly and use, reducing processing costs and errors.

Standard stock: Universal specifications, short lead time, and high cost-effectiveness.

Moderate precision: Commonly C5 grade, meeting general positioning and transmission needs.

High transmission efficiency: Ball circulation structure, low friction, and smooth operation.

Selectable rigidity and preload: Supports preload or micro-clearance configurations to adapt to different working conditions.

Easy maintenance: Supports lubrication replenishment, ensuring stable service life.

Wide application: Suitable for automated equipment, handling mechanisms, and small precision devices.
