REXROTH R165333820 KWD-035-FLS-C3-X-1 Ball Block FLS Long Slider
REXROTH R165333820 KWD-035-FLS-C3-X-1 Ball Block FLS Long Slider
REXROTH R165333820 KWD-035-FLS-C3-X-1 Ball Block FLS Long Slider
REXROTH R165333820 KWD-035-FLS-C3-X-1 Ball Block FLS Long Slider
REXROTH R165333820 KWD-035-FLS-C3-X-1 Ball Block FLS Long Slider
REXROTH R165333820 KWD-035-FLS-C3-X-1 Ball Block FLS Long Slider

REXROTH R165333820 KWD-035-FLS-C3-X-1 Ball Block FLS Long Slider

Inquiry Contact Us
  • Description
1

+86-13636560152
[email protected]
Inquiry
R165333820 Ball Slider, extremely high load capacity, FLS type, size 35, CS steel, XP-grade precision, C3-grade preload, standard sealing slider without ball chain.
Bosch Rexroth's FLS steel ball slider is a flange-type, extended, standard height linear motion component. It is designed for operating environments with extremely high rigidity and load-bearing capacity requirements, offering excellent load-bearing capacity.
Key Features and Performance of FLS Ball Slider:
High Load Capacity and High Rigidity: The extended design provides a larger contact area compared to standard length sliders (such as FNS), significantly improving the ability to withstand high loads and moments.
Flexible Installation: As a flange-type slider, it supports bolt mounting from the top or bottom, suitable for various mechanical structures.
Applications: Possesses extremely high load-bearing capacity, suitable for applications with the most demanding stiffness requirements.
Smooth operation: Under external loads, it can effectively reduce friction fluctuations and provide excellent running smoothness.
Rexroth ultra-high load capacity ball slides FLS are primarily used in the following industries:
 Machine tools, Industrial automation and robotics, Precision packaging and printing machinery, Assembly and conveying technology, and Electronics and semiconductor equipment.

Item

Specification

Part Number

R165333820

Ball Runner Type

FLS

Size

35

Preload Class

C3

Accuracy Class

XP

Sealing

SS – Standard Seal

Ball Chain

Without Ball Chain

Guide Block Width [mm]

100

Guide Block Length [mm]

139

Guide Block Height [mm]

40.40

Guide Block Height with Rail [mm]

48

Mass [kg]

2.25

Rated Dynamic Load [N]

66700

Rated Static Load [N]

11600

Rated Dynamic Torque Load [Nm]

1440

Rated Static Torque Load [Nm]

2500
