REXROTH R162381320 Ball Block KWD-020-SLS-C1-N-1 C1 Low Preload Block
REXROTH R162381320 Ball Block KWD-020-SLS-C1-N-1 C1 Low Preload Block
REXROTH R162381320 Ball Block KWD-020-SLS-C1-N-1 C1 Low Preload Block
REXROTH R162381320 Ball Block KWD-020-SLS-C1-N-1 C1 Low Preload Block

REXROTH R162381320 Ball Block KWD-020-SLS-C1-N-1 C1 Low Preload Block

Inquiry Contact Us
  • Description
1

+86-13636560152
[email protected]
Inquiry
The Bosch Rexroth R162381320 is an SLS type (narrow, long, standard height) ball slide block belonging to the ball guide system category. This R1623 ball slide block is commonly used in industrial automation applications requiring space-saving design and the ability to withstand extremely high loads and torques.
Key Features of the R1623 SLS Ball Slide Block:
Narrow Design: Suitable for applications with limited lateral installation space.
Extended Length: Offers higher load capacity and torsional rigidity compared to standard length slide blocks.
Interchangeability: This slide block can be used with ball guideways of the same size and accuracy class.
Material: Constructed from carbon steel.
Lubrication: Preliminary lubrication and rust prevention treatment is performed at the factory, typically using Dynalub 510 grease.
Rexroth SNS narrow ball slides are among the most common slide types used in industrial automation and precision manufacturing due to their narrow lateral design and high-precision operation.
Typical Application Industries
1. Machine Tools and Precision Metalworking
2. Electronics and Semiconductor Manufacturing
3. Measurement and Laboratory Technology
4. Automated Production Lines and Robotics
5. Packaging Machinery
6. Medical Equipment

Item

Specification

Part Number

R162381320

Ball Runner Type

SLS

Size

20

Preload Class

C1

Accuracy Class

H

Sealing

SS – Standard Seal

Ball Chain

Without Ball Chain

Guide Block Width [mm]

44

Guide Block Length [mm]

91

Guide Block Height [mm]

25.35

Guide Block Height with Rail [mm]

30

Mass [kg]

0.45

Rated Dynamic Load [N]

29600

Rated Static Load [N]

41800

Rated Dynamic Torque Load [Nm]

380

Rated Static Torque Load [Nm]

540
