The Bosch Rexroth R162371420 is an SLS type (narrow, long, standard height) ball slide block belonging to the ball guide system category. This R1623 ball slide block is commonly used in industrial automation applications requiring space-saving design and the ability to withstand extremely high loads and torques.
SLS Ball Slide Block Features:
High Interchangeability: Rexroth ball slide blocks are virtually interchangeable with ball guides of similar precision (such as the SNS/SNO models), allowing for flexible combinations to meet specific needs.
Four-Way Equal Load Capacity: Provides the same rated load in all four primary load directions, allowing for flexible installation.
Sealing and Lubrication: Equipped with an integrated all-round seal and initial lubrication using Dynalub 510 grease.
Narrow Design: The SLS R1623 narrow ball slide block is suitable for applications with limited lateral space.
Rexroth SLS narrow ball slides are among the most common slide types used in industrial automation and precision manufacturing due to their narrow lateral design and high-precision operation.
Typical Application Industries
1. Machine Tools and Precision Metalworking
2. Electronics and Semiconductor Manufacturing
3. Measurement and Laboratory Technology
4. Automated Production Lines and Robotics
5. Packaging Machinery
6. Medical Equipment

Item

Specification

Part Number

R162371420

Ball Runner Type

SLS

Size

30

Preload Class

C1

Accuracy Class

N

Sealing

SS – Standard Seal

Ball Chain

Without Ball Chain

Guide Block Width [mm]

60

Guide Block Length [mm]

119.7

Guide Block Height [mm]

35.35

Guide Block Height with Rail [mm]

42

Mass [kg]

1.10

Rated Dynamic Load [N]

46000

Rated Static Load [N]

66900

Rated Dynamic Torque Load [Nm]

800

Rated Static Torque Load [Nm]

1160
