REXROTH R162349420 Linear Guide Block SLS Type Long Slider KWD-045-SLS-C0-N-1

REXROTH SLS R162349420 is a 45mm narrow, extended, standard height ball slide from the SLS series, belonging to the R1623 series, and compatible with SNS/SNO type ball guides.

KWD-045-SLS-C0-N-1 is the complete code for the parameters of the R162349420 slide. 35 represents the size specification, SLS indicates that the slide has a narrow, long slide structure (high rigidity, saving lateral space), C0 indicates no preload rating, and N indicates standard accuracy rating.

Key features of the REXROTH SLS series ball slides:
① Narrow, extended standard height structure, requiring less lateral installation space; height is the same as conventional slides, eliminating the need for frame modifications, suitable for compact equipment layouts;
② Four-row ball layout, four-way equal rated load; extended slide body significantly improves anti-tipping and anti-torque capabilities, with excellent overall rigidity;
③ Multiple precision grades (N/P/H/SP/XP) are available; slides and guide rails of the same specifications are fully interchangeable, facilitating inventory and maintenance replacement;
④ Supports multiple preload levels (C0/C1/C2/C3), eliminating movement backlash, resulting in low frictional resistance, no crawling at low speeds, low noise, and suitability for high-speed applications;
