Rexroth R162322822 Carbon Steel Ball Runner Block WD-025-SLS-C2-X-1

R162322822 is a Bosch Rexroth SLS linear guide block (Ball Runner Block), belonging to the ball guide system, with C2 average preload and XP extra precision rating. The SLS block is a narrow, standard height, and extended type, possessing extremely high load-bearing capacity, suitable for applications with limited lateral installation space.

The core features of the R162322822 ball slider :

It employs a four-row ball bearing structure, achieving equal load capacity in four directions, providing strong load-bearing capacity and the ability to withstand torque loads;

The SLS narrow and extended design maintains high rigidity and high load-bearing performance even in space-constrained conditions;

It supports both long-term lubrication and initial pre-lubrication designs, enabling years of low-maintenance operation;

The standard sealing structure provides excellent dustproof and contamination resistance;

The slider and guide rail are interchangeable within the same precision class, facilitating maintenance and replacement.
