REXROTH R162312222 Accuracy Precision Ball Runner Block KWD-015-SLS-C2-P-1
REXROTH R162312222 Accuracy Precision Ball Runner Block KWD-015-SLS-C2-P-1
REXROTH R162312222 Accuracy Precision Ball Runner Block KWD-015-SLS-C2-P-1
REXROTH R162312222 Accuracy Precision Ball Runner Block KWD-015-SLS-C2-P-1

REXROTH R162312222 Accuracy Precision Ball Runner Block KWD-015-SLS-C2-P-1

Inquiry Contact Us
  • Description
1

+86-13636560152
[email protected]
Inquiry
R162312222 is a steel standard ball block slider, model KWD-015-SLS-C2-P-1, from the Bosch Rexroth SLS series. It features a narrow, long, standard-height SLS design, is compatible with 15mm wide guideways, and offers average preload (C2), accuracy precision (P), and ball chain sealing. It is specifically designed for high-precision linear motion applications with limited lateral space.
Key features of Rexroth SLS steel sliders:
① Utilizes a four-row ball bearing circulation structure, providing equal load capacity in four directions. It can simultaneously withstand radial, reverse, and lateral loads, offering excellent overall rigidity and load-bearing performance.
② The narrow, elongated design of the SLS slider effectively saves lateral installation space while ensuring high load capacity, making it suitable for compact equipment layouts.
③ The rolling friction structure ensures smooth operation and a low coefficient of friction, supporting high-speed (up to approximately 5 m/s) and high-acceleration conditions.
④ Ball bearing sliders can be equipped with a ball chain design, significantly reducing noise and wear, and improving service life and stability.
⑤ Factory pre-lubricated and supports long-term lubrication solutions, requiring minimal maintenance under optimal operating conditions.
⑥ Offers multiple preload and precision grades to flexibly match different application requirements in terms of rigidity, precision, and lifespan.

Item

Specification

Part Number

R162312222

Ball Runner Type

SLS

Size

15

Preload Class

C2

Accuracy Class

P

Sealing

SS – Standard Seal

Ball Chain

With Ball Chain

Guide Block Width [mm]

34

Guide Block Length [mm]

53.6

Guide Block Height [mm]

19.90

Guide Block Height with Rail [mm]

24

Mass [kg]

0.20

Rated Dynamic Load [N]

11500

Rated Static Load [N]

15600

Rated Dynamic Torque Load [Nm]

110

Rated Static Torque Load [Nm]

150
