R165341220 CS Steel Ball Block KWD-045-FLS-C1-P-1 FLS Precision Slider
R165341220 CS Steel Ball Block KWD-045-FLS-C1-P-1 FLS Precision Slider
R165341220 CS Steel Ball Block KWD-045-FLS-C1-P-1 FLS Precision Slider
R165341220 CS Steel Ball Block KWD-045-FLS-C1-P-1 FLS Precision Slider

R165341220 CS Steel Ball Block KWD-045-FLS-C1-P-1 FLS Precision Slider

Inquiry Contact Us
  • Description
1

+86-13636560152
[email protected]
Inquiry
The Bosch Rexroth R165341220 ball slide is a 45 -size flange-type extended high-precision ball slide (FLS). R165341220 FLS ball block features a carbon steel structure, P high precision, C1 slight preload, achieving high rigidity, low friction, and heavy load capacity, making it suitable for high-precision, high-load linear motion applications.
REXROTH FLS long ball slides are widely used in industrial applications where stability is paramount:
High Rigidity: Their extended design effectively reduces frictional fluctuations during operation, providing excellent smoothness.
Heavy Load Capacity: FLS ball slides are suitable for CNC machine tools, large automated assembly lines, robots, and heavy material handling systems.
High Compatibility: The slides and guideways are interchangeable, allowing users to freely combine different specifications of slides and guideways within the same accuracy class, greatly facilitating logistics and maintenance.
Rexroth ultra-high load capacity ball slides FLS are primarily used in the following industries:
Machine tools, Industrial automation and robotics, Precision packaging and printing machinery, Assembly and conveying technology, and Electronics and semiconductor equipment.

Item

Specification

Part Number

R165341220

Ball Runner Type

FLS

Size

45

Preload Class

C1

Accuracy Class

H

Sealing

SS – Standard Seal

Ball Chain

Without Ball Chain

Guide Block Width [mm]

120

Guide Block Length [mm]

174.1

Guide Block Height [mm]

50.30

Guide Block Height with Rail [mm]

60

Mass [kg]

4.30

Rated Dynamic Load [N]

111000

Rated Static Load [N]

190000

Rated Dynamic Torque Load [Nm]

3010

Rated Static Torque Load [Nm]

5120
