R165339420 High-precision ball guide slider REXROTH FLS Ball Slider
R165339420 High-precision ball guide slider REXROTH FLS Ball Slider
R165339420 High-precision ball guide slider REXROTH FLS Ball Slider
R165339420 High-precision ball guide slider REXROTH FLS Ball Slider
R165339420 High-precision ball guide slider REXROTH FLS Ball Slider
R165339420 High-precision ball guide slider REXROTH FLS Ball Slider

R165339420 High-precision ball guide slider REXROTH FLS Ball Slider

Inquiry Contact Us
  • Description
1

+86-13636560152
[email protected]
Inquiry
FLS type ball slider, ultra-high load capacity, R162119420 ball slider specification 35, CS steel slider, N-level precision, C0-level preload, standard seal, does not include ball chain.
Bosch Rexroth's FLS steel ball slider is a flange-type, extended, standard height linear motion component. It is designed for operating environments with extremely high rigidity and load-bearing capacity requirements, offering excellent load-bearing capacity.
Key Features and Performance of FLS Ball Slider:
High Load Capacity and High Rigidity: The extended design provides a larger contact area compared to standard length sliders (such as FNS), significantly improving the ability to withstand high loads and moments.
Flexible Installation: As a flange-type slider, it supports bolt mounting from the top or bottom, suitable for various mechanical structures.
Applications: Possesses extremely high load-bearing capacity, suitable for applications with the most demanding stiffness requirements.
Smooth operation: Under external loads, it can effectively reduce friction fluctuations and provide excellent running smoothness.
Highlights of Rexroth REXROTH ball slides:
  • Interchangeability with ball guide systems
  • Optional integrated wear-free sensing measurement system
  • Various accessories
  • Top mounts can be bolted on from the top and bottom of the ball slide
  • Increased stiffness under lifting and lateral loads by additional bolts secured in two holes in the center of the ball slide
  • All accessories are equipped with end-face fastening threads
  • High stiffness in all load directions - suitable for applications with only one slide per track
  • Integrated fully sealed
  • High torque load capacity
  • Optimized inlet geometry and a large number of balls minimize changes in elastic deflection
  • Smooth, noiseless operation due to optimized ball and ball chain return and guidance design
  • Various preload levels
Rexroth ultra-high load capacity ball slides FLS are primarily used in the following industries:
Machine tools, Industrial automation and robotics, Precision packaging and printing machinery, Assembly and conveying technology, and Electronics and semiconductor equipment.

Item

Specification

Part Number

R165339420

Ball Runner Type

FLS

Size

35

Preload Class

C0

Accuracy Class

N

Sealing

SS – Standard Seal

Ball Chain

Without Ball Chain

Guide Block Width [mm]

100

Guide Block Length [mm]

139

Guide Block Height [mm]

40.40

Guide Block Height with Rail [mm]

48

Mass [kg]

2.25

Rated Dynamic Load [N]

66700

Rated Static Load [N]

11600

Rated Dynamic Torque Load [Nm]

1440

Rated Static Torque Load [Nm]

2500
