R165333920 R1653 Linear Guide Slider REXROTH Steel Standard Ball Block
R165333920 R1653 Linear Guide Slider REXROTH Steel Standard Ball Block
R165333920 R1653 Linear Guide Slider REXROTH Steel Standard Ball Block
R165333920 R1653 Linear Guide Slider REXROTH Steel Standard Ball Block
R165333920 R1653 Linear Guide Slider REXROTH Steel Standard Ball Block
R165333920 R1653 Linear Guide Slider REXROTH Steel Standard Ball Block

R165333920 R1653 Linear Guide Slider REXROTH Steel Standard Ball Block

Inquiry Contact Us
  • Description
1

+86-13636560152
[email protected]
Inquiry
The Bosch Rexroth R165333920 is a high-precision carbon steel ball slide block (linear slide) with a long flange design (FLS). It is part of the High Precision Ball Guide System (BSHP) series. R165333920 35 specification FLS ball slide, C3 height preload, UP precision class.
FLS is a specific specification code for slide blocks in REXROTH Linear Motion Technology systems, representing Flange, Long, and Standard height. FLS slide blocks offer extremely high rigidity and load-bearing capacity, suitable for applications with the most demanding rigidity requirements.
Key Features and Performance of FLS Ball Slider:
  • High Load Capacity and High Rigidity: The extended design provides a larger contact area compared to standard length sliders (such as FNS), significantly improving the ability to withstand high loads and moments.
  • Flexible Installation: As a flange-type slider, it supports bolt mounting from the top or bottom, suitable for various mechanical structures.
  • Applications: Possesses extremely high load-bearing capacity, suitable for applications with the most demanding stiffness requirements.
  • Smooth operation: Under external loads, it can effectively reduce friction fluctuations and provide excellent running smoothness.
Rexroth ultra-high load capacity ball slides FLS are primarily used in the following industries:
Machine tools, Industrial automation and robotics, Precision packaging and printing machinery, Assembly and conveying technology, and Electronics and semiconductor equipment.

Item

Specification

Part Number

R165333920

Ball Runner Type

FLS

Size

35

Preload Class

C3

Accuracy Class

UP

Sealing

SS – Standard Seal

Ball Chain

Without Ball Chain

Guide Block Width [mm]

100

Guide Block Length [mm]

139

Guide Block Height [mm]

40.40

Guide Block Height with Rail [mm]

48

Mass [kg]

2.25

Rated Dynamic Load [N]

66700

Rated Static Load [N]

11600

Rated Dynamic Torque Load [Nm]

1440

Rated Static Torque Load [Nm]

2500
