The R165331920 is a flange-type extended high-rigidity ball slide block suitable for high-load, high-precision linear motion systems, and is one of the mainstream choices for CNC and automation equipment. The R165331920 standard ball slide block is available in 35mm size, with XP precision, C1 preload rating, and a standard seal without a ball chain.
Item |
Specification |
Part Number |
R165331920 |
Ball Runner Type |
FLS |
Size |
35 |
Preload Class |
C1 |
Accuracy Class |
UP |
Sealing |
SS – Standard Seal |
Ball Chain |
Without Ball Chain |
Guide Block Width [mm] |
100 |
Guide Block Length [mm] |
139 |
Guide Block Height [mm] |
40.40 |
Guide Block Height with Rail [mm] |
48 |
Mass [kg] |
2.25 |
Rated Dynamic Load [N] |
66700 |
Rated Static Load [N] |
11600 |
Rated Dynamic Torque Load [Nm] |
1440 |
Rated Static Torque Load [Nm] |
2500 |
