The Bosch Rexroth R162379422 ball slider is a narrow, long, standard-height ball slider with a carbon steel construction and a standard sealed ball chain design, achieving high rigidity, low friction, and heavy load capacity, making it suitable for high-precision, high-load linear motion applications.
The Bosch Rexroth KWD-030-SLS-C0-N-1 (R162379422) is a size 30 Slimline (SLS) Ball Runner Block made of carbon steel, designed for high-precision linear motion. It features a standard height, long length, standard accuracy (N), and is preload-free (C0), ideal for heavy-duty applications requiring smooth movement.
Item |
Specification |
Part Number |
R162379422 |
Ball Runner Type |
SLS |
Size |
30 |
Preload Class |
C0 |
Accuracy Class |
N |
Sealing |
SS – Standard Seal |
Ball Chain |
With Ball Chain |
Guide Block Width [mm] |
60 |
Guide Block Length [mm] |
119.7 |
Guide Block Height [mm] |
35.35 |
Guide Block Height with Rail [mm] |
42 |
Mass [kg] |
1.10 |
Rated Dynamic Load [N] |
43800 |
Rated Static Load [N] |
62200 |
Rated Dynamic Torque Load [Nm] |
760 |
Rated Static Torque Load [Nm] |
1080 |
