R162343820 Standard Ball Slider REXROTH Narrow Standard High Slider

The REXROTH SLS R162343820 is a 45mm narrow, extended, standard height ball slide from the SLS series, belonging to the R1623 series, and compatible with SNS/SNO type ball guides.

KWD-035-SLS-C3-X-1 is the complete code for the parameters of the R162343820 SLS slide. 35 represents the size specification, SLS indicates a narrow, long slide structure (high rigidity, saving lateral space), C3 indicates a high preload level, and X indicates an ultra-precision level.

Key Features of the R162343820 Ball Slider:

Compact Design: Narrow design suitable for applications with limited lateral space.

High Load Capacity: Extremely high load capacity and stiffness in all four main load directions.

Flexibility: Ball-free design, streamlined structure, and easy maintenance.

Compatibility: The slider is compatible with all SNS/SNO ball guides, and sliders and guides of different precision grades can be combined infinitely within their respective grades.

Universal Features: Equipped with a fully sealed system and threaded lubrication nozzles on all sides, supporting years of maintenance-free, long-lasting lubrication.
