R162332822 Bosch Rexroth Ball Runner Block KWD-035-SLS-C2-X-1 Block

The REXROTH R162332822 slider is a high-precision ball slider for Bosch Rexroth ball guide systems, belonging to the SLS series. KWD-035-SLS-C2-X-1 is the complete code for all parameters of the R162332822 slider.

SLS sliders refer to ball sliders with SLS (Slimline, Long, Standard-height) structural characteristics. They belong to high-precision, high-speed guide systems, featuring narrow width (Slim), long length (Long), and standard height (Standard), making them widely applicable in mechanical applications with limited lateral space.

Key features of the REXROTH SLS series ball slides:

① Narrow, extended standard height structure, requiring less lateral installation space; height is the same as conventional slides, eliminating the need for frame modifications, suitable for compact equipment layouts;

② Four-row ball layout, four-way equal rated load; extended slide body significantly improves anti-tipping and anti-torque capabilities, with excellent overall rigidity;

③ Multiple precision grades (N/P/H/SP/XP) are available; slides and guide rails of the same specifications are fully interchangeable, facilitating inventory and maintenance replacement;

④ Supports multiple preload levels (C0/C1/C2/C3), eliminating movement backlash, resulting in low frictional resistance, no crawling at low speeds, low noise, and suitability for high-speed applications;
