R162323822 SLS Narrow Linear Guide Slider KWD-025-SLS-C2-X-1

The R162323822 is a high-performance ball slider from Bosch Rexroth, with the full model code KWD-025-SLS-C3-X-1. The R162323822 SLS narrow ball slider belongs to Rexroth's Ball Rail Systems, is made of carbon steel (CS), and is designed for compact spaces and high-load applications.

The core features of the Bosch Rexroth SLS R162323822 slider :

It employs a four-row ball bearing structure, achieving equal load capacity in four directions, providing strong load-bearing capacity and the ability to withstand torque loads;

The SLS's narrow and extended design maintains high rigidity and high load-bearing performance even in space-constrained environments;

It supports both long-term lubrication and initial pre-lubrication designs, enabling years of low-maintenance operation;

The standard sealing structure provides excellent dust and contamination resistance;

The slider and guide rail are interchangeable within the same precision class, facilitating maintenance and replacement.
