R162322820 Rexroth SLS R1623 ball runner block for industrial robots

R162322820 is a Bosch Rexroth SLS linear guide block (Ball Runner Block), belonging to the ball guide system. SLS blocks are narrow, standard height, and extended types, offering extremely high load-bearing capacity, suitable for applications with limited lateral installation space.

KWD-025-SLS-C2-X-1 is the complete code for all parameters of the R162322820 slider. 25 represents the size specification, SLS indicates that the slider is a narrow and long slider structure (high rigidity, saving lateral space), C2 indicates average preload , and X indicates ultra-precision level.

The core features of the R162322820 slider are:

It employs a four-row ball bearing structure, achieving equal load capacity in four directions, providing strong load-bearing capacity and the ability to withstand torque loads;

The SLS narrow and extended design maintains high rigidity and high load-bearing performance even in space-constrained conditions;

It supports both long-term lubrication and initial pre-lubrication designs, enabling years of low-maintenance operation;

The standard sealing structure provides excellent dustproof and contamination resistance;

The slider and guide rail are interchangeable within the same precision class, facilitating maintenance and replacement.
