The PU07AR is an easy-to-operate, lightweight, and compact NSK miniature linear guide with smooth start-up and advanced lightweight design. Features include smooth start-up, lightweight construction, stainless steel construction, and low dust generation.
NSK PU Miniature Linear Guide Features:
* Low inertia, low dust generation in a compact series
* Low dust generation, stable operation
* Ultra-compact
* Standard series available in stainless steel versions
* Standardized series with protective plates
* Standardized interchangeable parts (interchangeable items) that can be purchased separately from the slider
NSK PU Miniature Linear Guide Applications:
⦁ Semiconductor manufacturing equipment
⦁ LCD panel manufacturing equipment
⦁ Medical devices
⦁ Optical microscope platforms
⦁ Microscope XY platforms
⦁ Fiber optic transmission
⦁ Miniature robotic arms
⦁ Computer peripherals
⦁ Pneumatic machinery

Item

Specification

Product Model

PU07AR

Slider Series

PU

Slider Type

AR

Specification

7

Individual Slider Model

PAU

Individual Guide Rail Model

P1U

Guide Rail Length

100-3000mm

Guide Slider Width[mm]

17

Guide Slider Length[mm]

23.4

Guide Slider Height[mm]

6.5

Guide Rail Width[mm]

7

Guide Rail Height[mm]

4.7

Height of Slider with Rail[mm]

8

Slider Weight[g]

8

Guide Rail Weight[g/100mm]

23

Rated Dynamic Load [N]

50Km-1090

100Km-860

Rated Static Load [N]

1370
