Due to their minimal assembly requirements, high precision, and stability, the YGL55R linear guides are widely used in industries such as consumer electronics assembly, precision testing platforms, and medical equipment. It is interchangeable with the HIWIN HGL55CA and can be seamlessly replaced in existing equipment, meeting requirements for lightweight, low inertia, and high speed. The YGL-LR is an ideal choice for applications requiring smooth operation and precise positioning.
Product Information | |
Product Name |
YOSO YGL55R Linear Guide |
Length |
Customized Length |
|
Features |
|
Alternative brands/models |
HIWIN HGL55CA |
Model No. |
YGL15R YGL25R YGL25LR YGL30R YGL30LR YGL35R YGL35LR YGL45R YGL45LR YGL55R YGL55LR |
Accuracy |
C H P SP UP |
Block Dust Protection |
SS / ZZ / DD / KK |
Material |
Carbon Steel |
Core Components |
Slider、 Guide |
Certificate： |
CE/ISO |
Typical application scenarios |
a. CNC Machine Tools b. Industrial Robots c. Automated Assembly Lines and Conveying Systems d. Laser Cutting and Electronics Equipment e. Medical and Inspection Equipment |
Our services |
According to drawings or samples for our customers to manufacture products. |
Product Package |
a. Plastic bag with box case or wooden case. We can provide shipping information to our customer at any time. |
