The REXROTH R162372222 is a 30mm steel standard ball slide block, featuring an SLS narrow, long, and standard height design. The R162372222 ball slide block has a precision grade of P and a preload grade of C2 (average).
Application Scenarios
Rexroth SLS sliders are commonly used in fields requiring high-speed, high-precision linear motion, such as automated machinery, machine tools, semiconductor manufacturing equipment, and packaging machinery.
Item |
Specification |
Part Number |
R162372222 |
Ball Runner Type |
SLS |
Size |
30 |
Preload Class |
C2 |
Accuracy Class |
P |
Sealing |
SS – Standard Seal |
Ball Chain |
With Ball Chain |
Guide Block Width [mm] |
60 |
Guide Block Length [mm] |
119.7 |
Guide Block Height [mm] |
35.35 |
Guide Block Height with Rail [mm] |
42 |
Mass [kg] |
1.10 |
Rated Dynamic Load [N] |
43800 |
Rated Static Load [N] |
62200 |
Rated Dynamic Torque Load [Nm] |
760 |
Rated Static Torque Load [Nm] |
1080 |
